Geometry:(based on a fork axle to crown length of 561 mm) enduro bearings for high rigidity and performance.rather steep seat tube angle for a good uphill riding position.with flip chip on the damper mount to adjust the geometry.Specifications: Application: All Mountain, Enduro Wheel Size: 29" Travel: 140 mm Size: S, M, L, XL Front Triangle Material: aluminium (6066) Rear Triangle Material: aluminium (6066) Linkage Design: supported single hinge Technical Information: Wheel Standard: 12 x 148 mm (Boost) Axle Type: 12 mm thru-axle Seatpost (Ø): 34.9 mm Seatpost Clamp(Ø): 38.5 mm Head Tube: 1 1/8" - 1.5" tapered Headset: ZS44 - ZS56 (top to bottom) Recommended Fork Axle to Crown: 551 mm Recommended Fork Travel: 150 - 160 mm Bottom Bracket Standard: Press Fit BB92 Shell Width: 92 mm Chainstay Guide: ISCG 05 Brake Mount: disc PM8 (direct mount 200 mm) Front Derailleur Mount: not possible Rear Shock Eye-to-Eye Measurement: 210 mm Rear Shock Stroke: 55 mm Rear Shock Bushing Width: 20 mm x 10 mm / 20 mm x 10 mm Bottle Cage Mounts: 1 Approved For: Rotor Size (max.): 220 mm Tyre Size (max.): 65 mm (width) Chainrings: 1x Fork Axle to Crown Size (max.): 571 mm Features: The result is a bike that delivers high performance both uphill and downhill, and won't let you down on difficult passages. Playful kinematics make the Meta TR dynamic, while double-row bearings on the frame prevent loss of rigidity at the joints. Once you reach the peak, you can dive straight on into mastering difficult descents. With a flip chip on the shock mount, it allows you to adjust the geometry to your needs and riding style. The COMMENCAL Meta TR frame for 29" forms the perfect basis for a playful, dynamic trail bike that will bring you pleasure both downhill and uphill. The frame can still fit a 27.The Meta TR 29" Frame from COMMENCAL conquers the trails with you Models are now fitted as standard with 29/27 wheels in sizes S/M and 29-inches in sizes L/XL A fork with 150mm or 160mm travel which provides comfort and/or safety depending where and how it's being used A semi-rigid frame which allows for better pedalling, a lighter weight and reduced maintenance Its development revolves around reliability as a priority: Particularly useful for those who want a longer bike.įor the rest, we are continuing with the winning formula that made this bike so successful. The choice of frame size is no longer limited by a seat tube that is too high when purchasing the complete bike. It is now possible to fit longer travel seat posts. It's a choice of reason which offers two advantages:
To keep current, we've worked on the smallest details that make the biggest differences. We believed in this bike many years ago and we have become real specialists. Max himself says: "It's better to have a good hardtail than a bad full-suspension bike". Our research confirms that it is the bike in our range that is most widely used, and to do most things! Enduro, off-road rides, urban missions, pump track laps.
